**Key FeaturesPatented field selectable fail safe/fail secureMulti voltage 10–30Vdc1000kg holding force4hr fire ratingMounting tabs as supplied standardAustralian designed and madeFully monitoredIntegrated door position (reed) switchSolenoid/LockedLatch positionApplicationsHigh traffic areasFire rated door setsOpen in/open out doorsSuitable for use with all access control systemsDoors requiring additional door position monitoringStandards and Compliance(Security) Australian Lock Standard (AS4145.2.2008)(Durability) Australian Lock Standard (AS4145.2.2008)Successfully fire rated up to 4hrs on fire door assemblies in accordance with AS1905.1. 2005CE ApprovedC-Tick CertifiedSpecificationsVoltage: Variable 10–30VdcCurrent: 200mA @ 12Vdc – 120mA @ 24VdcSolenoids: Rated for continuous useMonitoring: Latch /Strike locked /Door position (reed switch)Holding force: 1000kg static strength ratingEndurance: Cycle tested to 1.5 million operationsLatch: Suitable for 15mm latch bolt with 3mm door gapBody: Stainless SteelKeeper: Stainless SteelEnvironment: Operational temperature range -20ºC to 60ºCSpecifications StatementThe strike should be constructed of solid stainless steel, have a minimum holding force of 1000kg and an endurance rating of 1.5 million cycles. Monitoring must include independent latch and solenoid monitoring. The strike shall have an integrated reed switch for door position monitoring and used in conjunction with Lockwood 3572MAGSC mortice lock or tubularlatch with door magnet. Certifications must include CE, C-tick and 4 hr fire rating.
